CS3i Rugged Data Controller Built for the Toughest Survey Environments
.jpg)
Built for the Toughest Survey Environments
Brand
Apeks GNSSDistributor
Trivision Tech (India)Technology
Android 11 • 8-Core 2.0GHz • 4GB+64GB • 5" Sunlight Readable • IP68 • 9000mAhOverview
The Apeks CS3i is a military-grade rugged data controller that combines industrial toughness with Android 11 performance. Featuring an ultra-bright 5" sunlight-readable touchscreen, physical QWERTY keypad, 9000mAh hot-swappable battery, and full 4G/WiFi/Bluetooth connectivity, the CS3i is engineered to excel in the harshest surveying conditions — from -40°C arctic jobs to +75°C desert heat.
Key Product Features
- Android 11 OS with 8-core 2.0GHz processor + 4GB RAM + 64GB ROM
- 5" ultra-bright 720×1440p sunlight-readable capacitive touchscreen
- Physical QWERTY keypad + 5-point multi-touch for gloved operation
- 9000mAh high-capacity hot-swappable battery – 18h+ field work
- IP68 dust/waterproof + 1.5m drop resistance + MIL-STD-810G
- 4G full Netcom + Dual-band WiFi + Bluetooth 5.0 + NFC
- Built-in loud HD speaker + dual noise-cancelling microphones
- Rear 13MP camera with flash + ambient light/proximity sensors
- Supports all major GNSS receivers via Bluetooth/WiFi/USB
- Pre-installed ApeksSurv Pro software with full CAD/DXF support
- Operating temperature: -40°C to +75°C with wide-temp components
What We Provide
Apeks CS3i Rugged Data Controller- 9000mAh Li-ion Battery (pre-installed)
- USB-C Fast Charger + International Plugs
- Hand Strap + Stylus + Screen Protector
- ApeksSurv Pro Software Lifetime License
- Full India Warranty & Local Support by Trivision Tech
- Free Lifetime Firmware & Software Updates
Perfect For
Large-scale topographic surveys, construction layout in extreme weather, utility mapping in urban jungles, mining & oil/gas operations, defense & security mapping, forestry under dense canopy, marine & coastal surveys, and any mission-critical project where device failure is not an option.
Solution & Results
The CS3i eliminates downtime with its hot-swappable 9000mAh battery, survives drops and submersion, and delivers crystal-clear voice guidance even on noisy construction sites. Paired with Apeks AP60 Vision or any RTK receiver, it transforms complex surveys into simple, intuitive workflows — reducing crew fatigue and boosting daily productivity by up to 60% in extreme environments.
